13HPE发动机
来源：未知 作者：admin 时间：2019/10/30
| Engine designeation | 13 HPE 110 | 13 HPE 80 | 13 HPE 40 |
|
Crankshaft Power [kw](hp) |
81(110) | 59(80) | 29(40) |
|
Propeller shaft Power [kw](hp) |
78(107) | 57(78) | 27(38) |
|
Engine speed [min-1] |
4400 | 4000 | 4000 |
|
Displacement [1](in3) |
1,3(76) | 1,3(76) | 1,3(76) |
| Number of cylinders | 4 | 4 | 4 |
|
Bore/stroke [mm](in) |
69,6/82 (2,74/3,23) |
69,6/82 (2,74/3,23) |
69,6/82 (2,74/3,23) |
| Compression ratio | 17,6:1 | 17,6:1 | 17,6:1 |
|
Dry weight with TM 485A[kg] |
188 | 188 | 188 |
|
Dry weight with ZF 485D[kg] |
190 | 190 | 190 |
| Power Rating | B | C | D |
| Emission compliance | RCD STAGE ||2013/53/UE | ||
