20HPE发动机
来源：未知 作者：admin 时间：2019/10/30
| Engine designeation | 20HPE 180 | 20HPE 150 | 20HPE 120 | 20HPE 100 | 20HPE 40 |
|
Crankshaft Power [kw](hp) |
129(175) | 108(147) | 88(120) | 73(100) | 29(40) |
|
Propeller shaft Power [kw](hp) |
125(170) | 105(143) | 85(116) | 71(97) | 28(39) |
|
Engine speed [min-1] |
4100 | 4100 | 3800 | 3800 | 3200 |
|
Displacement [1](in3) |
2,0(119) | 2,0(119) | 2,0(119) | 2,0(119) | 2,0(119) |
|
Number of cylinders |
4 | 4 | 4 | 4 | 4 |
|
Bore/stroke [mm](in) |
83,0/90.4 (3,27/3,56) |
83,0/90.4 (3,27/3,56) |
83,0/90.4 (3,27/3,56) |
83,0/90.4 (3,27/3,56) |
83,0/90.4 (3,27/3,56) |
| Compression ratio | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 | 16,5:1 |
|
Dry weight with TM 485A[kg] |
250 | 250 | 250 | 250 | 250 |
|
Dry weight with ZF 485D[kg] |
261 | 261 | 261 | 261 | 261 |
| Power Rating | A | B | C | D | D |
